Product Summary

The 74HC597D is a high-speed Si-gate CMOS device. It is pin compatible with low power Schottky TTL(LSTTL). The device is specified in compliance with JEDEC standard no. 7A.

Parametrics

Quick reference data: (1)propagation delay(CL = 15 pF; VCC =5V):SHCP to Q:17ns, STCP to Q:25ns, PL to Q:21ns; (2)maximum clock frequency SHCP:96MHz; (3)input capacitance:3.5pF; (4)power dissipation capacitance per package:29pF.

Features

Features: (1)8-bit parallel storage register inputs; (2)Shift register has direct overriding load and clear; (3)Output capability: standard; (4)ICC category: MSI.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
74HC597D
74HC597D
NXP Semiconductors
Counter Shift Registers 8BIT SHIFT REGISTER W/INPUT LATCH
Data Sheet
Negotiable
74HC597D,652
74HC597D,652
NXP Semiconductors
Counter Shift Registers 8BIT SHIFT REGISTER
Data Sheet
0-1: $0.14
1-25: $0.13
25-100: $0.12
100-250: $0.12
74HC597DB,112
74HC597DB,112
NXP Semiconductors
Counter Shift Registers 8-BIT SHIFT REGISTER
Data Sheet
0-1: $0.32
1-25: $0.29
25-100: $0.28
100-250: $0.26
74HC597DB,118
74HC597DB,118
NXP Semiconductors
Counter Shift Registers 8-BIT SHIFT REG W/INPUT LATCH
Data Sheet
0-1: $0.32
1-25: $0.31
25-100: $0.30
100-250: $0.27
74HC597D,653
74HC597D,653
NXP Semiconductors
Counter Shift Registers 8-BIT SHIFT REG W/INPUT LATCH
Data Sheet
0-1: $0.25
1-25: $0.23
25-100: $0.18
100-250: $0.18
74HC597DB
74HC597DB
NXP Semiconductors
Counter Shift Registers 8-BIT SHIFT REGISTER
Data Sheet
Negotiable
